Wide Series Welded Chain With Attachment

WDH480 Welded Mill Chain Wide Series Welded Chain With Attachment

DOWNLOAD

Introduction

Introduction

Product brief description

WDH Series chains have all parts through hardened. They are specially designed for loads and operating conditions imposed by drag conveyor service.

Product details description

JINQIU CHAIN, as a prominent chains manufacturer, we offer a complete range of WH and WR narrow series and WDH wide series of welded steel chains. They are mainly used in woodworking, grain and oil processing and paper making industries and more.
Our welded steel chains are specially designed for demanding applications where strong impact and material wearing and lots of dust. These power transmission product or conveyor part are engineered from special alloy steels using finite element analysis technology and best-in-class manufacturing technology and equipment. As a result, the welded cranked link chains have excellent resistance to high load impact and long lasting wear resistance while providing low cost.
Jointed with various attachments in virtue of welding or bolting methods, the welded steel chains can meet the needs for diversity of different production lines.

Chain No.	Average Pitch	E(mm)	Sidebar		Pin		F(mm)	Min.Ult. Strength (KN)
Chain No.	Average Pitch	E(mm)	T(mm)	H(mm)	D(mm)	A(mm)	F(mm)	Min.Ult. Strength (KN)
WDH102	127.0	162.00	9.70	38.10	19.05	232.50	197.00	226.7
WDH104	152.4	104.78	9.70	38.10	19.05	173.30	136.53	226.7
WDH110	152.4	228.60	9.70	38.10	19.05	296.00	260.50	235.0
WDH113	152.4	228.60	12.70	38.10	22.23	311.50	270.20	297.8
WDH120	152.4	222.25	12.70	50.80	22.23	301.60	260.35	311.5
WDH112	203.2	228.60	9.70	38.10	19.05	296.00	260.50	250.0
WDH116	203.2	330.20	9.53	44.45	19.05	395.00	358.78	250.0
WDH118	203.2	336.55	12.70	50.80	22.35	425.45	377.90	400.5
WDH480	203.2	279.40	12.70	50.80	22.23	366.90	323.85	311.5
WDH480XHD	203.2	279.40	15.88	50.80	25.40	380.85	330.20	543.0
